The Mister Hitches shank is designed to be a reliable and compatible component in weight distribution systems. Its three-pin hole design allows for various adjustments and caters to different towbar receiver setups, including short shank receivers found on Ford Rangers. The shank is built to withstand the demands of towing and is rated for heavy loads.
Features
- Standard Shank: This shank is the standard shank found in Mister Hitches Weight Distribution Kits. It's designed to be compatible with Mister Hitches Weight Distribution Systems and the Multi-Hitch Mix 'N' Match System.
- Material: The shank is made from solid steel, ensuring durability and strength.
- Compatibility: This shank is suitable for Ford Ranger short shank receivers.
- Adjustment: It features three pin holes to provide greater adjustment options. The measurements for the pin holes are as follows:
- End of Shank to 1st Hole: 50mm
- End of Shank to 2nd Hole: 82.5mm
- End of Shank to 3rd Hole: 125mm
- Drop: The drop measurement, from the top of the shank to the top of the Weight Distribution Hitch (WDH) ball platform, is 63.5mm.
- Rise: The rise measurement, from the top of the shank to the top of the WDH ball platform, is 165mm.
- Shank Overall Height: The overall height of the shank is 225mm.
- Shank Shape: The shank is solid steel with a square shape, measuring 50.8mm.
- Rating: The shank is rated at 4.4T (4.4 tons) and is designed for use as part of your weight distribution system setup.
- Versatility: These shanks can be drilled or cut without a loss of integrity, providing flexibility and adaptability for your towing needs.
| SKU | MHWDS10 |
|---|---|
| Brand | Mr Hitches |
